P1545 BMW Fault Code

Description:

EGR Flow Insufficient Detected The EGR system is monitored during steady state driving conditions while the EGR is commanded on.
The test fails when the signal from the DPF EGR sensor indicates that EGR flow is less than the desired minimum. Vacuum supply EGR valve stuck closed EGR valve leaks vacuum EGR flow path restricted EGRVR circuit shorted to PWR VREF open to D.P.F. EGR sensor D.P.F. EGR sensor downstream hose off or plugged EGRVR circuit open to PCM VPWR open to EGRVR solenoid D.P.F. EGR sensor hoses both off D.P.F. EGR sensor hoses reversed Damaged EGR orifice tube Damaged EGRVR solenoid Damaged PCM Perform KOER self-test and look for DTC P1545 as an indication of a hard fault.

P1545 Code Symptoms :

OBD P1545 code and tailpipe testing are two different approaches to identify vehicles in need of repair. The OBD system looks for broken or malfunctioning emissions control components and P1545, while tailpipe tests sample a vehicle's exhaust to see if it is above or below certain prescribed limits. Given the robust nature of today's emissions control components, it is entirely possible for an individual component to malfunction without leading to an immediate increase in emissions at the tailpipe.

In such cases, other components (like the catalyst) can temporarily compensate for the part that is broken however, these other components can only do double duty for so long before they, too, begin to malfunction. In addition, OBD also monitors for and other malfunctions in the fuel system problems that traditional tailpipe tests were not designed to identify. Most state and local areas also include a gas cap pressure test as part of an emission inspection.

Diagnosis And Repairing P1545

P1545 OBD2 reports a sensor fault, replacement of the sensor is unlikely to resolve the underlying problem. The fault is most likely to be caused by the systems that the sensor is monitoring, but might even be caused by the wiring to the sensor itself.

How to fix P1545 code ?

• Dirty Oil
• Camshaft Position Sensor harness is open or shorted
• Faulty Crankshaft Position Sensor (POS)
• Intake Valve Timing Control Solenoid Valve harness is open or shorted

At this point we are assuming that the fuses and relays are good. You will need to locate the PCM/TCM and the power input signal circuit using your vehicle information source.

Unplug the connector from the PCM/TCM, place the ignition switch in the ON position, and probe the appropriate circuit with the positive test lead of the DVOM.
